Dovetail
| Standard | Available Options |
DOVETAIL 5' Dove Tail | Pop-Up Center Straight Deck *No Charge |
RAMPS Spring Assist Deck Level | 96" Slide In Option Tex-Ramps |
Jack
| Standard | Available Options |
| Drop Leg Jacks | 2-Speed Jacks |
| Hydraulic Jacks *Contact Office |
Storage
| Standard | Available Options |
| Standard Tool Box | Big Tool Box *Upgrades Neck to 12" I-Beam |
| Side Tool Box |
Frame
| Standard | Available Options |
| 12" X 14lb I-Beam | 12" X 19lb |
| Bridge Truss |
Axle
| Standard | Available Options |
| 7,000lb EZ Lube w/ 2 Brakes Tires: 235/80/R16 10PLY | (2) 8,000lb Brake Axles GVWR: 16,000lbs |
| (3) 7,000lb Brake Axles GVWR: 21,000lbs Tires: 14PLY w/Spare |
Neck
| Standard |
| 10" Channel |
Bed Width
| Standard |
| 102" Deck Standard |
CROSSMEMBERS
| Standard | Available Options |
| 3" Channel on 18" Centers | 16" Centers 12" Centers |
WHEELS
| Standard |
| Black/Silver |
TIRES
| Standard | Available Options |
| 235/80/R16 10PLY | 14PLY w/Spare |
RAMPS
| Standard | Available Options | |
| Spring Assist Deck Level | 96" Slide In Option | Tex-Ramps |
COUPLER
| Standard |
| 2 5/16" Adjustable RAM |
RAMPS
| Standard | Available Options |
| #2 Treated Pine | Steel |
| features | |
|---|---|
| BED WIDTH | 102" Deck Standard |
| FRAME | 12" X 14lb I-Beam |
| CROSSMEMBERS | 3" Channel on 18" Centers |
| TONGUE/NECK | 10" Channel |
| JACK | Dual 12K Drop Leg Jacks |
| AXLES | 7,000lb EZ Lube w/2 Brakes |
| DOVETAIL | 5' Dove Tail |
| WHEELS | Black/Silver |
| TIRES | 235/80/R16 10PLY |
| SPARES | Spare & Mount Included |
| RAMPS | Spring Assist Deck Level |
| COUPLER | 2 5/16" Adjustable RAM |
| STORAGE | Standard Tool Box |
| FLOOR | #2 Treated Pine |
| LIGHTS | Rubber Mount LED |
**35' Trailers Automatically Upgraded to a Bridge Truss.
**40' Trailers Automatically Upgraded to a 12" X 19lb I-Beam Frame & Bridge Truss
| AVAILABLE OPTIONS | ||||
|---|---|---|---|---|
| FRAME | 12" X 19lb | Bridge Truss | ||
| CROSSMEMBERS | 16" Centers | 12" Centers | ||
| JACK | 2-Speed Jacks | Hydraulic Jacks *Contact Office | ||
| AXLES | (2) 8,000lb Brake Axles GVWR:16,000lbs (3) 7,000lb Brake Axles GVWR:21,000lbs | |||
| DOVETAIL | Pop-Up Center | Straight Deck *No Charge | ||
| TIRES | 14PLY w/Spare | |||
| RAMPS | 96" Slide In Option | Tex-Ramps | ||
| STORAGE | Big Tool Box *Upgrades Neck to 12" I-Beam | Side Tool Box | ||
| FLOOR | Steel | |||
| Light Dozer Package: Dove Cross Members/Dozer Ramps | ||||
| TIE-DOWNS | Winches | D-Rings | Winch Track | |
| Winch Straps | ||||
- 102" X 25'
- 102" X 30'
- 102" X 32'
- 102" X 35'*
- 102" X 40'**
-
*35' Trailers Automatically Upgraded to a Bridge Truss.
**40' Trailers Automatically Upgraded to a 12" X 19lb I-Beam Frame & Bridge Truss
Black
Smoked Charcoal
Industrial Gray
White
Midnight Blue
Kubota Orange
Candy Apple Red
John Deere Green
Cat Yellow
