Axle
| Standard | Available Options | |||||
| (1) 7,000lb Brake : 7,000 GVWR | (2) 7,000lb Brake : 14,000 GVWR | (3) 7,000lb Brake 21,000 GVWR | ||||
| Tires: 235/80/R16 10PLY | 235/80/R16 14PLY | 235/80/R16 18PLY | ||||
Necks
Schedule-40 Pipe |
Uprights
| Standard | Available Options |
8" Channel | 10" Channel Included on 28' - 32' Lengths |
Height
6'6" |
SIDES
1" X 3" Tubing |
Coupler
2 5/16" Gooseneckg |
Gates
| Standard | Available Options |
Butterfly | Combo Slider |
Front Escape Door |
Roof
| Standard | Available Options |
Roof Bows | Canvas |
Steel |
Cut Gates
| Standard | Available Options | ||
Every 8' | Extra Cut Gate | Removable Cut Gate | |
Fenders
| Standard |
| 10GA Brush |
Jack
| Standard | Available Options |
12K Drop Leg Jack | Dual 12K Drop Leg Jack |
Air Vents
| Available Options | |
|---|---|
| Butterfly | Fold Down |
| standard features | |
|---|---|
| FRAME | 4" x 4" x 1/4" Angle |
| JACK | 12K Drop Leg Jack |
| GOOSENECK | 8" Channel |
| UPRIGHTS | Schedule-40 Pipe |
| ROOF | Roof Bows |
| FENDERS | 10ga Brush |
| HEIGHT | 6'6" |
| SIDES | 1" X 3" Tubing |
| COUPLER | 2 5/16" Gooseneck |
| WHEELS | Black/Silver |
| TIRES | 235/80/R16 10PLY |
| GATES | Butterfly |
| FLOORS | #2 Treated Pine |
| SPARE | Spare & Mount |
| CUT GATES | Every 8' |
| Available Options | |||
|---|---|---|---|
| AXLE | (1) 7,000lb Brake : 7,000 GVWR | (2) 7,000lb Brake : 14,000 GVWR | (3) 7,000lb Brake 21,000 GVWR |
| FRAME | 4" X 4" X 5/16" Included on 28' - 32' Lengths | ||
| JACK | Dual Jacks | ||
| GOOSENECK | 10" Channel Included on 28' - 32' Lengths | ||
| ROOF | Canvas | Steel | |
| TIRES | 235/80/R16 14PLY | 235/80/R16 18PLY | |
| GATES | Combo Slider | Front Escape Door | |
| FLOORS | Rubber | ||
| CUT GATES | Extra Cut Gate | Removable Cut Gate | |
| 6' 8" X 12' (SINGLE) | 7,000lbs |
| 6' 8" X 16' | 14,000lbs |
| 6' 8" X 20' | 14,000lbs |
| 6' 8" X 24' | 14,000lbs |
| 6' 8" X 28' | 21,000lbs |
| 6' 8" X 32' | 21,000lbs |
Black
Smoked Charcoal
Industrial Gray
White
Midnight Blue
Kubota Orange
Candy Apple Red
John Deere Green
Cat Yellow
