Texline Tandem Dual Series
Bed Width
| Standard |
102" Deck Standard |
FRAME
| Standard | Available Options |
12" X 19lb I-Beam | 12" X 22lb |
CROSSMEMBERS
| Standard | Available Options |
3" Channel on 16" Centers | 12" Centers |
Neck
| Standard |
12x19 Pound I- Beam |
Axles/tires
| Standard | Available Options | ||||
| 10,000lb Oil Bath w/Brakes | (2) 12,000lb Oil Bath GVWR:25,000lbs | (2) 12,000lb Hydraulic Disc GVWR:25,000lbs | (2) 15,000lb Oil Bath GVWR:25,900lbs | (2) 15,000lb Hydraulic Drum GVWR:25,900lbs | |
| Standard | Available Options | ||||
| Tires235/80/R16 10PLY | (9) 235/80/R16 14PLY | (9) 235/75/R17.5 18PLY | (5) 235/80/R16 18PLY Super Single *No Charge | ||
Jack
| Standard | Available Options |
Dual 12K Drop Leg Jacks | 2-Speed Jacks |
| Hydraulic Jacks |
Dovetail/Ramps
| Standard | Available Options |
|
DOVETAIL 5' Dove Tail |
Pop-Up Center Straight Deck *No Charge |
|
RAMPS Spring Assist Deck Level |
96" Slide In Option Tex-Ramps |
COUPLER
| Standard | Available Options |
25K Gooseneck | King Pin Adapter |
FLOORS
| Standard | Available Options | |
#2 Treated Pine | Steel | Winch Track |
STORAGE
| Standard | Available Options | |
| Standard Tool Box | Big Tool Box | Side Tool Box |
Build Your Own.
You Deserve the best
- Configure Select your size, options, and finishes.
- Submit Send your custom build to a dealer.
- Connect A dealer reaches out with final pricing.
Image shown may include optional features not included in the standard model. Winch track also available under Floor options (+$24/ft).
Tandem Dual Series
Your Build
Standard Build
$15,545.00
Estimated MSRP
$15,545.00
Image shown may include optional features not included in the standard model. Winch track also available under Floor options (+$24/ft).
| standard features | |
|---|---|
| BED WIDTH | 102" Deck Standard |
| FRAME | 12" X 19lb I-Beam |
| CROSSMEMBERS | 3" Channel on 16" Centers |
| TONGUE | 10" Channel |
| JACK | Dual 12K Drop Leg Jack |
| AXLES | 10,000lb Oil Bath w/Brakes |
| DOVETAIL | 5' Dove Tail |
| WHEELS | Black/Silver |
| TIRES | 235/80/R16 10PLY |
| RAMPS | Spring Assist Deck Level |
| COUPLER | 2 5/16" Adjustable RAM |
| STORAGE | Standard Tool Box |
| FLOORS | #2 Treated Pine |
| LIGHTS | Rubber Mount LED |
| available options | |||||
|---|---|---|---|---|---|
| FRAME | 12" X 22lb | ||||
| CROSSMEMBERS | 12" Centers | ||||
| AXLES | (2) 12,000lb Oil Bath GVWR:25,000lbs | ||||
| (2) 12,000lb Hydraulic Disc GVWR:25,000lbs | |||||
| (2) 15,000lb Oil Bath GVWR:25,900lbs | |||||
| (2) 15,000lb Hydraulic Drum GVWR:25,900lbs | |||||
| DOVETAIL | Pop-Up Center | Straight Deck *No Charge | |||
| TIRES | (9) 235/80/R16 14PLY | (9) 235/75/R17.5 18PLY | (5) 235/80/R16 18PLY Super Single *No Charge | ||
| TIE-DOWNS | Winches | D-Rings | Winch Straps | ||
| RAMPS | 96" Slide In Option | Tex-Ramps | |||
| COUPLER | King Pin Adapter | ||||
| STORAGE | Big Tool Box | Side Tool Box | |||
| FLOORS | Steel | Winch Track | |||
| LIGHTS | Light Dozer Package: Dove Cross Members/Dozer Ramps | ||||
| ADDITIONAL OPTIONS | Pierced Beam Option | 6' X 8' Deck on Neck | Winch Track | Hutch Suspension | |
- 102" X 25'
- 102" X 30'
- 102" X 32'
- 102" X 35'
- 102" X 40'
- 102" X 45'
Black
Smoked Charcoal
Industrial Gray
White
Midnight Blue
Kubota Orange
Candy Apple Red
John Deere Green
Cat Yellow
