Axles
| Standard | Available Options |
7,000lb EZ Lube w/(2)Brakes Tires: ST235/80/R16 10PLY
| Upgrade to 16,000lb GVWR, (2) 8K Brake Axles, 7" Channel Frame, Tongue & Tire Upgrade: 235/80/R16 14PLY 215/75/R17.5 18PLY |
FRAME
| Standard | Available Options |
6" Channel | 7" Channel |
JACK
| Standard | Available Options |
12K Drop Leg Jack | Dual 12K Drop Leg Jack |
TONGUE
| Standard | Available Options | |
6" Channel | Gooseneck Upgrade | GN I-Beam Neck Included in Big Box Package |
CROSSMEMBERS
| Standard | Available Options | |
3" Channel on 16" Centers | 12" Centers | |
Gates
| Standard | Available Options |
Butterfly | 3-Way Metering Gate |
SIDES
| Standard | Available Options | |
24" Sheet Metal 10ga | 36" 10ga Sheet Metal | 48" 10ga Sheet Metal |
COUPLER
| Standard |
14K Adjustable |
FLOOR
| Standard | Available Options | |
24" Sheet Metal 10ga | 7ga Sheet Metal | |
Hoist
| Standard |
Scissor Lift |
TIE-DOWNS
| Standard |
Stake Pockets & (4) D-Rings |
STORAGE
| Standard | Available Options | |
A-Frame Pump Box | Gooseneck Big Box Package w/Dual Jacks | |
RAMPS
| Standard |
Slide-In Ramps |
| Standard eatures | |
|---|---|
| AXLE | 7,000lb EZ Lube w/(2) Brakes |
| FRAME | 6" Channel |
| JACK | 12K Drop Leg Jack |
| TONGUE | 6" Channel |
| CROSSMEMBERS | 3" Channel on 16" Centers |
| TOP | Tarp Included |
| FENDERS | 14ga Tread Plate |
| HOIST | Scissor Lift |
| SIDES | 24" Sheet Metal 10ga |
| COUPLER | 14K Adjustable |
| WHEELS | Black/Silver |
| TIRES | ST235/80/R16 10PLY |
| GATES | Butterfly |
| FLOOR | 10ga Sheet Metal |
| TIE-DOWNS | Stake Pockets & (4) D-Rings |
| STORAGE | A-Frame Pump Box |
| RAMPS | Slide-In Ramps |
| available options | ||||
|---|---|---|---|---|
| AXLE | *Upgrade to 16,000lb GVWR, (2) 8K Brake Axles, 7" Channel Frame, Tongue & Tire Upgrade | |||
| FRAME | 7" Channel | |||
| JACK | Dual 12K Drop Leg Jack | |||
| TONGUE | Gooseneck Upgrade | GN I-Beam Neck Included in Big Box Package | ||
| CROSSMEMBERS | 12" Centers | |||
| SIDES | 36" 10ga Sheet Metal | 48" 10ga Sheet Metal | ||
| TIRES | 235/80/R16 14PLY | 215/75/R17.5 18PLY | ||
| GATES | 3-Way Metering Gate | |||
| FLOOR | 7ga Sheet Metal | |||
| SPARE | Spare Mount | 235/80/R16 10PLY | 14PLY | |
| STORAGE | Gooseneck Big Box Package w/Dual Jacks | |||
| 83" X 12' | 14,000lbs |
| 83" X 14' | 14,000lbs |
| 83" X 16' | 14,000lbss |
Black
Smoked Charcoal
Industrial Gray
White
Midnight Blue
Kubota Orange
Candy Apple Red
John Deere Green
Cat Yellow
